Waterproof Transformers

Home >  Products >  Transformers >  Waterproof Transformers

IP65 Waterproof Transformer, Circular 12V/24V DC Power Supply Outdoor LED Waterproof Power Supply 100W-500W

Designed for outdoor applications, this IP65-rated waterproof transformer delivers reliable power conversion for LED lighting systems. Available in both 12V and 24V DC output options, this circular power supply features robust protection against water, dust, and harsh weather conditions. With power options ranging from 100W to 500W, it's perfect for commercial and landscape lighting installations. The durable aluminum housing ensures excellent heat dissipation while providing long-term protection against corrosion. Its compact circular design allows for versatile mounting options, making it ideal for outdoor signage, garden lighting, architectural illumination, and other exterior applications. This power supply incorporates multiple safety protections including short-circuit, overload, and over-temperature safeguards, ensuring stable performance and extended service life in challenging outdoor environments.

  • Overview
  • Recommended Products
Product Usage
Waterproof transformer suitable for plug lawn laser light, Christmas tree light string, LED lighting, LED light string, Copper string lights, Low-pressure
pumps, Motor toys, LED light-emitting module, Underwater system, Fountains, Swimming pools , Gardening...

Small appliances:
electronicrefrigerator, electric fan, mosquito lamp, air purifiers, humidifiers, meat grinder, oven etc.
Protection Level:
Working Status light: LED status light
Waterproof grade: IP65/IP67/IP68
Epoxy resin potting: Heat conduction resin potting
Protection device: Temperature protection
Waterproof transformer is made of imported high magnetic flux low-loss silicon steel sheet with double-layer insulation and
high-strength lacquer wrap, which has excellent electrical characteristics.
Advantage:
Short-circuit protection
Overload protection
Temperature protection
IP65 Waterproof Transformer, Circular 12V/24V DC Power Supply  Outdoor LED Waterproof Power Supply 100W-500W details
One cable in, 4 cable out
Technical specifications:
* Input voltage: Customized
* Frequency: 50-60Hz
* Output voltage: Customized
* According to: EN61558
* Test/insulating voltage: 4kV AC RMS
* Construction class: II
* Insulation class: B (130°C)
* Ambient temp. (ta): 25°C



IP65 Waterproof Transformer, Circular 12V/24V DC Power Supply  Outdoor LED Waterproof Power Supply 100W-500W supplier
Model
Dimension(mm)
Power (VA/W)
A
B
C
D
E
F
G
EKE50
124
60
90
110
175
195
8
50W-150W
EKE150
124
60
90
110
175
195
8
150W-300W
EKE300
138
69
90
110
190
210
10
300W-600W
EKE400
150
81
114
135
210
230
10
400W-600W
EKE600
150
81
114
135
210
230
10
300W-600W
EKE1000
185
96
120
140
237
256
10
600W-1000W
*The parameter is only for reference as typical data, customized are welcomed.
*We are able to provide you 20VA to 25KVA toroidal transformer.
