High-power Nanocrystalline Core High-temperature Resistant Specifically Designed New Energy Equipment
- New Energy Extreme-Condition Performance: Superior magnetic properties and thermal stability, maintains optimal efficiency even at elevated temperatures for renewables and EV charging.
- Nanocrystalline Structure Advantages: Minimal power loss, excellent frequency response, and high saturation flux density, reducing system size and weight.
- Broad High-Power Application Scope: Ideal for renewable energy systems, EV charging stations, and industrial power conversion equipment.
- Durable Premium Material Build: Outperforms traditional cores with enhanced service life and consistent performance for demanding power electronics.
- Global Compatibility & Easy Assembly: Multiple I/O configurations (240V input, 380V/480V output), 50Hz/60Hz support, and cut core design for hassle-free maintenance.
- Overview
- Recommended Products
This advanced Nanocrystalline Core is specifically engineered for new energy applications demanding exceptional performance under extreme conditions. Featuring superior magnetic properties and outstanding thermal stability, this high-power core maintains optimal efficiency even at elevated temperatures. Its unique nanocrystalline structure ensures minimal power losses, excellent frequency response, and remarkable saturation flux density. Ideal for renewable energy systems, electric vehicle charging stations, and industrial power conversion equipment, this core delivers reliable performance while reducing overall system size and weight. The advanced material composition provides enhanced durability and extended service life compared to traditional cores. Perfect for manufacturers seeking high-efficiency solutions in demanding power electronics applications where thermal management and performance consistency are crucial.
Products Description
Material |
High quality CRGO steel with low iron-loss and high permeability |
Features |
Lower core loss, no
leakage magnetic flux,
excellent DC bias
characteristics, high
magnetic permeability
range from 250 to 1200.
|
Applications |
50Hz and 400Hz transformers.current transformers.chokes and other magnetic
components of
electronic equipments.
|
Manufacturing Process
Smashing → Laser-welding → Slitting →Winding →Chamfering→ Annealing → Varnish → Testing → Packing
Product Paramenters
Model |
Core Size (MM) |
Finished Size (MM) |
Cross Area (cm2) |
Average Path Length(CM) |
One-turn Loop Independence AL(μH) 1Khz,0.25V |
||||||||
OD |
ID |
H |
OD |
ID |
H |
Ae |
Lm |
AL(min) |
|||||
EK0603 |
6.0 |
3.0 |
3.2 |
6.5 |
2.5 |
3.8 |
0.037 |
1.41 |
13.0 |
||||
EK0903 |
9.0 |
5.0 |
3.2 |
9.5 |
4.5 |
3.8 |
0.050 |
2.20 |
11.5 |
||||
EK1003 |
10.0 |
7.0 |
3.2 |
10.5 |
6.5 |
3.8 |
0.037 |
2.67 |
7.0 |
||||
EK1210 |
12.0 |
8.7 |
10.0 |
12.6 |
8.1 |
10.6 |
0.129 |
3.25 |
20.0 |
||||
EK1405 |
14.0 |
9.0 |
4.5 |
14.5 |
8.5 |
5.1 |
0.088 |
3.61 |
12.0 |
||||
EK2108 |
21.3 |
13.5 |
8.0 |
22.1 |
12.8 |
9.0 |
0.243 |
5.46 |
22.0 |
||||
EK4304 |
43.0 |
35.0 |
4.0 |
43.6 |
34.4 |
4.6 |
0.125 |
12.25 |
5.0 |
||||
Two series of toroidal core
A series
B series core commonly used as a replacement of EI and other toroidal transformers with lower magnetic loss requirement.
Material thickness: 0.30mm, 0.27mm, 0.23mm
A round core wound by automatic machines with one continuous tape of CRGO silicon steel and annealed in a tunnel furnace under the protection of inert gases.
Material thickness: 0.30mm, 0.27mm, 0.23mm, 0.10mm, 0.08mm and 0.05mm.
B series
B series core commonly used as a replacement of EI and other toroidal transformers with lower magnetic loss requirement.
Material thickness: 0.30mm, 0.27mm, 0.23mm
