Amorphous and Nanocrystalline Material Amorphous Toroid Core with Gap

Amorphous and Nanocrystalline Material Amorphous Toroid Core with Gap

This high-performance amorphous toroid core combines advanced nanocrystalline materials with precision engineering to deliver superior magnetic properties. Featuring a strategically designed gap, this core offers excellent control over inductance and prevents magnetic saturation in high-current applications. The unique amorphous structure ensures minimal core losses, high permeability, and outstanding temperature stability, making it ideal for power transformers, chokes, and high-frequency switching applications. With its exceptional energy efficiency and compact size, this toroid core provides reliable performance in modern power electronics, EMI filters, and industrial equipment. The carefully engineered gap allows for customized inductance values while maintaining consistent performance across varying operating conditions. Trust this professional-grade core for your demanding electromagnetic applications where efficiency and reliability are paramount.

Overview
Recommended Products

Company Introduction

Product Description

Amorphous and Nanocrystalline Material Amorphous Toroid Core with Gap manufacture

Toroidal transformer:

Single-phase toroidal transformers, power range
from 20VA to 5000VA. Designed and tested
according to EN61558. Suitable for installation
in electronically equipment.
Designed as a safety isolating transformer with
separate insulated windings and prepared for
class II equipment.
Short circuit and overload protected with
thermal fuse on primary side. Up to 50% less
weight than a similar conventional transformer.
Low magnetisation currents and no-load losses.

Technical specifications:

* Input voltage: Customized
* Frequency: 50-60Hz
* Output voltage: Customized
* According to: EN61558
* Test/insulating voltage: 4kV AC RMS
* Construction class: II
* Insulation class: B (130°C)
* Ambient temp. (ta): 25°C

Mounting (2 kinds)
1.Parts for mounting supplied(rubber mats, screws and nuts)
2.Central proxy resin encapsulation and drilling.

Amorphous and Nanocrystalline Material Amorphous Toroid Core with Gap supplier

*The parameter is only for reference as typical data, customized are welcomed.
*We are able to provide you 20VA to 25KVA toroidal transformer.

Rated Power (VA)	Voltage Regulation (%)	Efficiency (%)	Dimension(mm)			Weight (Kg)
Rated Power (VA)	Voltage Regulation (%)	Efficiency (%)				Weight (Kg)	Height(C)	Diameter(A)
30	16	83	30	80	0.60
100	11	88	42	100	1.30
150	7.30	90	45	115	1.85
200	6.2	91	53	123	2.30
250	5.60	92	53	128	2.60
300	5.30	93	55	135	3.00
400	4.60	94	60	140	3.80
500	4.30	95	66	146	4.50
800	4.0	95	85	160	7.00
1000	3.80	96	90	165	8.50
1200	3.30	96	95	168	9.00
1500	3.0	96	100	173	9.50
2000	2.90	96	110	183	13.00
4000	2.2	97	135	245	23.00
5000	2.1	98	145	270	28.00
