220V120V12V Swimming Pool Equipment Underwater Light IP67 Waterproof Grade Waterproof Transformer Encapsulated Transformer

220V120V12V Swimming Pool Equipment Underwater Light IP67 Waterproof Grade Waterproof Transformer Encapsulated Transformer

Enhance your pool's ambiance with our professional-grade underwater lighting transformer. This versatile power supply unit is specifically designed for swimming pool lighting systems, supporting multiple voltage options including 220V, 120V, and 12V for worldwide compatibility. Built to rigorous safety standards, the transformer features IP67 waterproof protection through advanced encapsulation technology, ensuring reliable performance in wet environments. The fully sealed construction prevents water ingress while providing excellent heat dissipation for extended service life. Perfect for both residential and commercial pool applications, this transformer delivers stable power output for consistent underwater illumination. Its compact design allows for easy installation while meeting international safety regulations. Trust in our transformer to power your pool lighting system safely and efficiently, creating the perfect underwater atmosphere for evening swimming and entertainment.

Overview
Recommended Products

220V120V12V Swimming Pool Equipment Underwater Light IP67 Waterproof Grade Waterproof Transformer Encapsulated Transformer manufacture

Product Usage

Waterproof transformer suitable for plug lawn laser light, Christmas tree light string, LED lighting, LED light string, Copper string lights, Low-pressure
pumps, Motor toys, LED light-emitting module, Underwater system, Fountains, Swimming pools , Gardening...

Small appliances:

electronicrefrigerator, electric fan, mosquito lamp, air purifiers, humidifiers, meat grinder, oven etc.

Protection Level:

Working Status light: LED status light
Waterproof grade: IP65/IP67/IP68
Epoxy resin potting: Heat conduction resin potting
Protection device: Temperature protection

Waterproof transformer is made of imported high magnetic flux low-loss silicon steel sheet with double-layer insulation and
high-strength lacquer wrap, which has excellent electrical characteristics.

Advantage:

Short-circuit protection

Overload protection
Temperature protection

220V120V12V Swimming Pool Equipment Underwater Light IP67 Waterproof Grade Waterproof Transformer Encapsulated Transformer factory

One cable in, 4 cable out

Technical specifications:

* Input voltage: Customized
* Frequency: 50-60Hz
* Output voltage: Customized
* According to: EN61558
* Test/insulating voltage: 4kV AC RMS
* Construction class: II
* Insulation class: B (130°C)
* Ambient temp. (ta): 25°C

_Model	Dimension(mm)								Power (VA/W)
_Model		A	B	C	D	E	F	G	Power (VA/W)
EKE50	124	60	90	110	175	195	8	50W-150W
EKE150	124	60	90	110	175	195	8	150W-300W
EKE300	138	69	90	110	190	210	10	300W-600W
EKE400	150	81	114	135	210	230	10	400W-600W
EKE600	150	81	114	135	210	230	10	300W-600W
EKE1000	185	96	120	140	237	256	10	600W-1000W

*The parameter is only for reference as typical data, customized are welcomed.
*We are able to provide you 20VA to 25KVA toroidal transformer.
