Ultra Stable Toroidal Transformer Core for Medical Imaging Equipment 240V Input/380V 480V 50Hz 60Hz Amorphous Cut Core for Power

Ultra Stable Toroidal Transformer Core for Medical Imaging Equipment 240V Input/380V 480V 50Hz 60Hz Amorphous Cut Core for Power

Premium Amorphous Material: Superior magnetic properties and minimal core losses vs. silicon steel cores.
Global Compatibility: Multiple I/O configurations (240V input, 380V/480V output) and 50Hz/60Hz support.
Easy Assembly & Stable Flux: Cut core design for hassle-free maintenance and uniform magnetic flux distribution.
Sensitive Equipment Friendly: Excellent temperature stability and low-noise operation, ideal for MRI/CT/X-ray machines.
Long-Term Reliability: Robust build ensures durable performance even under continuous operation for medical facilities.

Overview
Recommended Products

This premium toroidal transformer core delivers exceptional stability and reliability for medical imaging applications. Engineered with high-grade amorphous materials, it offers superior magnetic properties and minimal core losses compared to traditional silicon steel cores. The versatile design accommodates multiple input/output configurations including 240V input and 380V/480V output, while supporting both 50Hz and 60Hz frequencies for global compatibility. The cut core construction allows for easy assembly and maintenance while maintaining optimal magnetic flux distribution. With excellent temperature stability and low noise operation, this transformer core is ideal for sensitive medical equipment like MRI, CT, and X-ray machines where consistent power supply is crucial. The robust build quality ensures long service life even under continuous operation, making it a reliable choice for medical facility power systems.

Ultra Stable Toroidal Transformer Core for Medical Imaging Equipment 240V Input/380V 480V 50Hz 60Hz Amorphous Cut Core for Power factory

Products Description

Ultra Stable Toroidal Transformer Core for Medical Imaging Equipment 240V Input/380V 480V 50Hz 60Hz Amorphous Cut Core for Power supplier

Material	High quality CRGO steel with low iron-loss and high permeability
Features	Lower core loss, no leakage magnetic flux, excellent DC bias characteristics, high magnetic permeability range from 250 to 1200.
Applications	50Hz and 400Hz transformers.current transformers.chokes and other magnetic components of electronic equipments.

Manufacturing Process

Smashing → Laser-welding → Slitting →Winding →Chamfering→ Annealing → Varnish → Testing → Packing

Ultra Stable Toroidal Transformer Core for Medical Imaging Equipment 240V Input/380V 480V 50Hz 60Hz Amorphous Cut Core for Power manufacture

Ultra Stable Toroidal Transformer Core for Medical Imaging Equipment 240V Input/380V 480V 50Hz 60Hz Amorphous Cut Core for Power details

Product Paramenters

Model	Core Size (MM)					Finished Size (MM)					Cross Area (cm²)	Average Path Length(CM)	One-turn Loop Independence AL(μH) 1Khz,0.25V
Model		OD	ID	H	OD	ID	H	Ae	Lm	AL(min)
EK0603	6.0	3.0	3.2	6.5	2.5	3.8	0.037	1.41	13.0
EK0903	9.0	5.0	3.2	9.5	4.5	3.8	0.050	2.20	11.5
EK1003	10.0	7.0	3.2	10.5	6.5	3.8	0.037	2.67	7.0
EK1210	12.0	8.7	10.0	12.6	8.1	10.6	0.129	3.25	20.0
EK1405	14.0	9.0	4.5	14.5	8.5	5.1	0.088	3.61	12.0
EK2108	21.3	13.5	8.0	22.1	12.8	9.0	0.243	5.46	22.0
EK4304	43.0	35.0	4.0	43.6	34.4	4.6	0.125	12.25	5.0

Two series of toroidal core

A series

A round core wound by automatic machines with one continuous tape of CRGO silicon steel and annealed in a tunnel furnace under the protection of inert gases.

Material thickness: 0.30mm, 0.27mm, 0.23mm, 0.10mm, 0.08mm and 0.05mm.

B series

B series core commonly used as a replacement of EI and other toroidal transformers with lower magnetic loss requirement.
Material thickness: 0.30mm, 0.27mm, 0.23mm

Material

Product packaging
